Aiphone IX-DVF Web Setting Manual

123
Configuring the Station
6.4.4 Transmission Trigger
Configure the SIF sending trigger when “Program Type (→page 122)” is set to "0010" or "0100-1111."
■ Begin Outgoing Call
■ Begin Communication (Source)
■ End Communication
Description A SIF command is sent when an outgoing call is made.
Settings • Checked: Send
• Unchecked: Do not send
Default values Unchecked: Do not send
Description A SIF command is sent when a call begins.
Settings • Checked: Send
• Unchecked: Do not send
Default values Unchecked: Do not send
Description A SIF command is sent when a call ends.
Settings • Checked: Send
• Unchecked: Do not send
Default values Unchecked: Do not send

Aiphone IX-DVF Specifications

General

Resolution	720p
Video Compression	H.264
Ingress Protection	IP65
Vandal Resistance	IK08
Operating Voltage	48 VDC (PoE)
Power Source	PoE (IEEE 802.3af)
Operating Temperature	-40° to 140°F (-40° to 60°C)
Communication	IP
Call Tone	Chime
