- 25 -
Specifications
Refer to "Operation Manual" for IXG-MK, IXG-DM7, IXG-DM7-HID.
■ IXG-DM7-BOX
■ IXGW-LC
■ IXGW-GW
Mounting Flush wall-mounted
Materials SPCC t1.6
Dimensions 156 mm (6-1/8") [W] × 317 mm (12-1/2") [H] × 60 mm (2-3/8") [D]
Mass Approx. 1.8 kg (4.0 lbs)
Power PoE (IEEE802.3af Class 0 standard)
Current consumption Standby 2.1 W, Max. 4.4 W (48 VDC)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Relay 20 relay outputs
Protocol IPv4, IPv6, TCP, UDP, HTTP, HTTPS, IGMP, MLD, FTP, DHCP, NTP, DNS, TLS
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission Unicast and Multicast
Operating temperature -10 °C to +50 °C (+14 °F to +122 °F)
Mounting Wall-mounted
Materials Self-extinguishing resin
Color Middle gray
Dimensions 210 mm (8-1/4") [W] × 108.5 mm (4-1/4") [H] × 61 mm (2-3/8") [D]
Mass Approx. 310g (0.69 lbs)
Power PoE (IEEE802.3af Class 0 standard)
Current consumption Standby 2.4 W, Max. 2.9 W (48 VDC)
LAN Ethernet (10BASE-T, 100BASE-TX), Auto MDI/MDI-X-compatible
Protocol IPv4, IPv6, TCP, UDP, SIP, HTTPS, RTP, RTCP, SRTP, SRTCP, IGMP, MLD, SFTP, DHCP,
NTP, DNS, MQTT, ICE, DTLS, SDP
Encryption system TLS1.0, TLS1.1, TLS1.2
Packet transmission Unicast and Multicast
Channel 8
Operating temperature -10 °C to +50 °C (+14 °F to +122 °F)
Mounting Wall-mounted (DIN rail)
Materials Self-extinguishing resin
Color Black
Dimensions 210 mm (8-1/4") [W] × 108.5 mm (4-1/4") [H] × 61 mm (2-3/8") [D] (62.2mm (2-7/16") [D] with DIN
rail)
Mass Approx. 320g (0.71 lbs) (approx. 350g (0.78 lbs) with DIN rail)
