Aiphone IXG Series - Example of Multi-Building System

- 6 -
■ Example of Multi-building System
Maximum number of buildings: 99 buildings
A maximum of 9,999 of the following stations and adaptors can be connected with a multi-building system:
IXG-2C7(-L), IXG-DM7(-HID), IXG-MK, IX-MV7-*, IXGW-LC, IXGW-GW, IX-RS-*
※1
, door stations (IX-DV, IX-DVF(-*),
IX-SS-2G
※1
, IX-SSA(-*), IX-EA)
A maximum of 9,999 mobile devices can be connected with entire multi-building system:
ASP-IXGI, ASP-IXGA
※1 Scheduled to be connectable during the third quarter of 2020
IXG-DM7(-HID)
IXG-MK
IX-DV
“Example of Standard System (→page 5)”
Tenant buildings
Main building
Tenant building 1
Tenant building 2
Tenant building 99
PoE Switch
(third party)
PoE Switch
(third party)
PoE Switch
(third party)
PoE Switch
(third party)
PoE Switch
(third party)
Network camera
(third party)
Mobile device
(third party)
PC (third party)
Wi-Fi,
3G/4G
