A.2 Tables of specifications - DHT Series
For dimensions, weights, and connection sizes, see the drawing of the dryer model provided at purchase.
Type of dryer: Refrigerated
Power supply: 115, 230, 460 Volt / single or three
phase / 60Hz
Refrigerant type: R-134A
Chemical Composition: HFC
All Models R-134a
Parameter
Description Air Pressure
Air Inlet
Temperature
Ambient
Temperature
Evaporator
Temperature
Suction Gauge
Reading
Discharge Gauge
Reading
Optimum 175 psig 180 (°F) 100 (°F) 45 - 50 (°F) 40 - 45 psig 160 - 230 psig
Maximum 232 psig 200 (°F) 120 (°F) 60 (°F) 60 psig 260 psig
Minimum 40 psig 40 (°F) 40 (°F) 32 (°F) 28 psig 80 psig
