| VF, DHT, AES Series Manual
Refrigerated Air Dryer User Manual
38
Type of dryer: Refrigerated
Power supply: 460, 575 VAC / three phase / 60Hz
Refrigerant type: R-404A
All Models R-404a
Parameter
Description Air Pressure
Air Inlet
Temperature
Ambient
Temperature
Evaporator
Temperature
Suction Gauge
Reading
Discharge Gauge
Reading
Optimum 100 psig 100 (°F) 100 (°F) 35 - 42 (°F) 75 - 90 psig 290 - 400 psig
Maximum 200 psig 140 (°F) 120 (°F) 60 (°F) 130 psig 410 psig
Minimum 40 psig 40 (°F) 35 (°F) 32 (°F) 75 psig 160 psig
A.3 Tables of specifications - AES Series
For dimensions, weights, and connection sizes, see the drawing of the dryer model provided at purchase.
