VF, DHT, AES Series Manual |
Refrigerated Air Dryer User Manual
51
AIRECLPART# QTY DESCRIPTION
AG3934264 1 ENCLOSURE,16x16x6
AG3934265 1 B ACKPLATEFITS16x16ENCLOSURE
AG3939621 1 COMMUNICATIONMODULE
AG3480020 1 ML‐1100PLC
AG3992107 1 C400HMIDISPLAY
AG3933345 11 TE RMINALBLOCK,GRAY,J3
AG3933672 3 TERMINALBLOCK,BLUE,J3
AG3253101 4 TERMINALBLOCK,GREEN/YELLOW,J3
AG3251901 6 ENDANCHOR
AG3480612 3 TERMINALBLOCK,GRAY,J10
AG3480613 1 TERMINALBLOCK,GREEN/YELLOW,J10
AG3934654 1 POWERSUPPLY,24VDC,30WATTS
AG3948855 1 RELAY,DPDT
AG3939622 1 S WITCH,2‐POSITION
AG3939623 1 LIGHT,PILOT,120VAC,GREEN
A IRECLPART# QTY DESCRIPTION
AG3287701 2 CONNECTOR,CONDUIT,90°,3/8"
AG3313601 2 CONNECTOR,CONDUIT,90°,1/2"
AG3480860 5 CONDUIT,SEALTITE,1/2"
AG3480861 5 CONDUIT,SEALTITE,3/8"
1C932208 ‐US 1 PLCCABLE
AG3254701 1 TRANSFORMER,150VA
AG3948950 2 FUSE,.75AMP
AG3998925 1 XC643CONTROLLER
AG3998926 1 COMMUNICATIONCABLE
AG3374201 37 WIRE,16AWG,RED
AG3374901 14 WIRE,16AWG,WHITE
AG3371801 13 WIRE,16AWG,BLUE
AG3465901 13 WIRE,16AWG,WHITE/BLUESTRIPE
AG3372301 14 WIRE,16AWG,GREEN
AG3373901 10 WIRE,16AWG,ORANGE
B.3 AES Series - Air-Cooled Models 600 - 2,000 scfm; 3 Phase, 460 Volt, 60 Hz
