AIREDALE R410A - Downflow Direct Expansion Performance Data (Continued); Performance Data Tables (X100;X200;X1 X1); Unit Operating Limits

'RZQÀRZ'LUHFW([SDQVLRQ
Performance Data
X100 / X200 / X1X1
Ambient Temperature (°C)
Model
Air On 25 30 35 40 46
Temp. (°C) TC SC TC SC TC SC TC SC TC SC
/ %RH (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW)
SC15D030-X200-0 22 / 50 34.2 30.7 33.0 31.1 31.6 30.1 30.0 29.0 28.1 27.3
1 x CR50 24 / 45 35.4 35.2 34.2 34.0 32.8 32.7 31.4 31.2 29.5 29.4
26 / 40 37.0 37.0 35.7 35.7 34.4 34.4 32.9 32.9 31.0 31.0
SC15D035-X200-0 22 / 50 39.4 36.8 37.8 35.7 36.0 34.5 34.2 33.2 32.0 31.1
1 x CR50 24 / 45 40.7 40.4 39.1 38.9 37.5 37.3 35.8 35.5 33.6 33.4
26 / 40 42.4 42.4 40.8 40.8 39.2 39.2 37.4 37.4 35.2 35.2
SC15D040-X200-0 22 / 50 44.3 39.9 43.0 39.2 41.2 38.0 39.2 36.7 36.8 35.0
1 x CR65 24 / 45 45.4 44.2 44.0 43.6 42.3 42.0 40.5 40.3 38.3 38.1
26 / 40 47.2 47.2 45.8 45.8 44.1 44.1 42.4 42.4 40.1 40.1
SC15D044-X200-0 22 / 50 47.3 40.8 46.3 40.5 44.4 39.9 42.3 38.8 39.8 37.0
1 x CR80 24 / 45 48.5 45.3 47.4 44.9 45.4 44.2 43.4 43.1 41.0 40.8
26 / 40 50.0 49.9 48.8 48.8 47.0 47.0 45.2 45.2 42.8 42.8
SC18D037-X200-0 22 / 50 39.8 37.3 38.1 36.2 36.2 34.9 34.4 33.5 32.3 31.4
1 x CR50 24 / 45 41.2 40.9 39.5 39.3 37.8 37.6 36.0 35.8 33.8 33.6
26 / 40 42.8 42.8 41.2 41.2 39.5 39.5 37.7 37.7 35.4 35.4
SC18D040-X200-0 22 / 50 44.4 41.3 42.6 40.0 40.6 38.7 38.5 37.3 36.1 35.1
1 x CR50 24 / 45 45.8 45.5 44.0 43.8 42.2 41.9 40.2 40.0 37.8 37.6
26 / 40 47.6 47.6 45.9 45.9 44.1 44.1 42.1 42.1 39.7 39.7
SC18D044-X200-0 22 / 50 49.4 45.7 47.4 44.4 45.3 42.9 43.1 41.5 40.5 39.4
1 x CR65 24 / 45 50.9 50.6 49.0 48.7 47.0 46.7 45.0 44.7 42.4 42.2
26 / 40 53.0 53.0 51.1 51.1 49.1 49.1 47.1 47.1 44.5 44.5
SC18D048-X1X1-0 22 / 50 55.7 49.9 54.7 49.6 52.4 48.1 50.0 46.5 47.0 44.5
2 x CR50 24 / 45 57.0 55.2 55.9 54.8 53.7 53.4 51.5 51.2 48.7 48.4
26 / 40 59.1 59.1 58.0 58.0 55.9 55.9 53.7 53.7 50.9 50.9
SC18D055-X1X1-0 22 / 50 62.9 52.1 61.3 51.6 58.6 50.8 55.7 49.9 52.0 47.8
2 x CR50 24 / 45 64.6 57.9 62.8 57.2 60.0 56.3 57.1 55.2 53.4 53.0
26 / 40 66.4 64.0 64.5 63.2 61.8 61.8 59.0 59.0 55.7 55.7
TC = Total Cooling
SC = Sensible Cooling
THR = Total Heat Rejection
(1) All data quoted is gross
'HGXFWIDQPRWRUJDLQIRUQHWWGXWLHVUHIHUWR0HFKDQLFDO'DWDVHFWLRQ
Operating Limits
Indoor Air Temperature +18°C to +28°C
,QGRRU5+WR%DVHGXSRQ&'U\%XOE
Outdoor Temperature -20°C to +46°C
Precision Air Conditioning SmartCool™ 16 - 60
47
SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical X-TypeDF
