AIREDALE R410A - Downflow Direct Expansion Mechanical Data (SC18 D048-SC18 D055)

SC18D048-X1X1-0 SC18D055-X1X1-0
Standard Condenser Match
2 x CR50 2 x CR50
Capacity
Nom Cooling (Gross)
(1) kW 53.67 60.04
Capacity Steps
2 2
Dimensions – W x D x H
mm 1800 x 890 x 1980 1800 x 890 x 1980
Weight – Machine / Operating
(3) kg 560 / 570 570 / 580
Construction
3DQHOV*DOYDQLVHG6KHHW6WHHO(SR[\%DNHG3RZGHU3DLQW±%ODFN*UH\5$/
Material/Colour
Frame: Anodised Aluminium Frame with aluminium corners, Epoxy
EDNHG3RZGHU&RDWHG3DLQW%ODFN*UH\5$/
Evaporator
5LÀHG&RSSHU7XEH7XUEXODWHG+\GURSKLOLF&RDWHG$OXPLQLXP)LQV
Cooling/Dehum Stages
2 / 2 2 / 2
Fan Motor
%DFNZDUGV&XUYHG&HQWULIXJDOGLUHFWGULYH
Motor Type
EC EC
Quantity x Motor Size
(4) kW 2 x 3.1 2 x 3.1
Speed @25Pa / Maximum ESP
rpm 1230 / 1560 1320 / 1560
Maximum ESP
Pa 410 410
1RPLQDO$LUÀRZ
m³/s 4.1 4.1
Fan Power Input (Fan Gain)
(2) kW 2.70 2.70
Compressor – Scroll
&RQ¿JXUDWLRQ
Twin Circuit – Single Compressors
Quantity
2 2
Oil Charge Volume
l 2 x 3.2 2 x 3.2
Oil Type
POE
Refrigeration
Twin Circuit
Refrigerant Control and Type
Electronic Expansion Valve
Refrigerant Type
R410A
Holding Charge
Inert Gas
Charge (per circuit)
(5) kg 4.8 4.8
Connections
Liquid (sweat)
in 5/8 5/8
Discharge (sweat)
in 7/8 7/8
Condensate Drain Hose
mm 22 22
Filtration
'LVSRVDEOHWR%6(1*
Quantity
8 8
Electric Heating (Total)
kW 15 15
+XPLGL¿HU
Capacity
kg/hr 8 8
Drain Pump Flow Rate
l/m 7 7
Feed / Drain
´%63)%UDLGHG)OH[LEOH+RVHPP+RVH&RQQHFWLRQ
Hot Water Condensate Pump
Head
m 5 5
Flow
l/m 10.8 10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m 4 4
Flow
l/m 1.7 1.7
Drain
PP4XDUWHU7XUQ3ODVWLFµ%DUE¶&RQQHFWLRQ
Upgrade Fan Motor - EC Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Quantity x Motor Size
(4) kW 2 x 3.5 2 x 3.5
Speed @ 25Pa / Maximum ESP
rpm 1240 / 1620 1240 / 1620
Maximum ESP
Pa 500 500
Fan Power Input (Fan Gain)
(2) kW 2.82 2.82
'RZQÀRZ'LUHFW([SDQVLRQ
Mechanical Data
SC18D048 - SC18D055
SmartCool™ 16 - 60
Precision Air Conditioning
64 SmartCool Technical Manual 7525371 V1.2.0_03_2013
