AIREDALE R410A - Downflow Direct Expansion Sound Data; Sound Data Tables (SC09 D Models)

'RZQÀRZ'LUHFW([SDQVLRQ
Sound Data
G%$LVWKHRYHUDOOVRXQGOHYHOPHDVXUHGRQWKH$VFDOH
(2) All sound data measured at nominal conditions, Discharge Air, Return air and case breakout is sound power.
Sound Measurement
2YHUDOOG%$
)UHTXHQF\+]G%
63 125 250 500 1000 2000 4000 8000
SC09D016-X100-0
Discharge Air
90.6 94.0 96.9 89.4 86.4 83.8 82.4 76.4 83.3
Return Air
89.4 94.6 98.5 87.8 85.9 79.6 77.7 76.9 83.6
&DVH%UHDNRXW
70.0 72.2 79.3 70.0 63.0 62.2 64.1 57.3 47.7
Sound Pressure @ 3m
64.0 66.2 73.3 64.0 57.0 56.1 58.1 51.3 41.7
SC09D019-X100-0
Discharge Air
93.4 96.0 97.4 92.6 89.3 86.5 84.6 77.8 88.1
Return Air
92.2 96.6 99.0 91.0 88.8 82.3 79.9 78.3 88.4
&DVH%UHDNRXW
71.9 74.0 79.8 73.2 65.5 63.9 65.9 58.9 52.0
Sound Pressure @ 3m
65.8 68.0 73.8 67.2 59.5 57.8 59.9 52.9 46.0
SC09D023-X100-0
Discharge Air
94.7 96.8 97.4 93.7 90.7 87.6 85.7 78.4 90.1
Return Air
93.6 97.4 99.0 92.1 90.2 83.4 81.0 78.9 90.4
&DVH%UHDNRXW
73.0 74.8 79.8 74.4 67.2 65.1 67.3 59.5 53.3
Sound Pressure @ 3m
66.9 68.8 73.8 68.4 61.1 59.1 61.3 53.5 47.2
SC09D026-X100-0
Discharge Air
94.7 96.8 97.4 93.7 90.7 87.6 85.7 78.4 90.1
Return Air
93.6 97.4 99.0 92.1 90.2 83.4 81.0 78.9 90.4
&DVH%UHDNRXW
73.4 74.9 79.8 74.4 67.3 65.3 68.2 59.8 53.4
Sound Pressure @ 3m
67.3 68.9 73.8 68.4 61.3 59.3 62.2 53.8 47.4
SC12D020-X200-0
Discharge Air
75.0 84.1 83.3 78.1 72.1 68.1 63.1 57.4 50.2
Return Air
78.5 94.1 89.1 82.9 74.8 64.9 58.1 53.9 42.5
&DVH%UHDNRXW
64.7 75.9 75.3 60.7 55.8 58.1 56.1 54.1 53.1
Sound Pressure @ 3m
58.6 73.4 69.2 54.7 49.8 52.1 50.1 48.1 47.1
SC12D023-X200-0
Discharge Air
80.3 87.7 89.3 83.8 77.6 71.5 68.3 62.2 56.2
Return Air
83.1 94.1 93.7 87.4 79.8 70.6 63.7 59.9 47.5
&DVH%UHDNRXW
68.3 77.6 80.3 65.0 58.0 61.3 59.4 56.5 55.1
Sound Pressure @ 3m
62.3 73.4 74.3 59.0 52.0 55.3 53.3 50.5 49.1
SC12D029-X200-0
Discharge Air
83.1 90.0 92.2 86.7 80.6 73.6 70.7 64.7 59.0
Return Air
85.2 94.1 95.6 89.5 82.1 73.2 66.2 62.5 50.3
&DVH%UHDNRXW
73.4 78.6 82.3 67.6 65.1 68.8 65.1 62.9 61.5
Sound Pressure @ 3m
67.4 73.4 76.3 61.5 59.1 62.8 59.0 56.9 55.4
SC12D033-X2X2-0
Discharge Air
85.9 92.5 95.0 89.8 83.8 75.8 73.1 67.5 61.8
Return Air
87.2 94.1 97.3 91.5 84.2 75.7 68.5 64.7 53.4
&DVH%UHDNRXW
73.8 79.5 84.0 69.4 63.0 65.8 66.1 65.5 64.5
Sound Pressure @ 3m
67.8 73.4 77.9 63.4 57.0 59.8 60.1 59.4 58.5
SC12D036-X200-0
Discharge Air
85.9 92.5 95.0 89.8 83.8 75.8 73.1 67.5 61.8
Return Air
87.2 94.1 97.3 91.5 84.2 75.7 68.5 64.7 53.4
&DVH%UHDNRXW
74.7 79.5 84.0 69.5 66.4 69.3 66.9 65.6 60.2
Sound Pressure @ 3m
68.7 73.4 77.9 63.5 60.4 63.2 60.9 59.5 54.2
SmartCool™ 16 - 60
Precision Air Conditioning
48 SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical
X-Type DF
