AIREDALE R410A - Downflow Chilled Water Mechanical Data (SC15 D035-SC15 D060)

SC15D035-C000-0 SC15D060-C000-0
Capacity
Nom Cooling (Gross)
(1) kW 35.5 55.7
Dimensions - W x D x H
mm 1500 x 890 x 1980 1500 x 890 x 1980
Weight - Machine / Operating
(3) kg 370 / 400 400 / 430
Construction
3DQHOV*DOYDQLVHG6KHHW6WHHO(SR[\%DNHG3RZGHU3DLQW%ODFN*UH\5$/
Material/Colour
Frame: Anodised Aluminium Frame with aluminium corners, Epoxy
EDNHG3RZGHU&RDWHG3DLQW%ODFN*UH\5$/
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water Volume
l 24.98 39.29
Water Flow Rate
l/s 1.69 2.66
Pressure Drop
kPa 29.53 53.48
Fan & Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Motor Type
EC EC
Quantity x Motor Size
(4) kW 2 x 1.7 2 x 3.6
Speed @25Pa ESP / Maximum ESP
rpm 1160 / 1770 1650 / 2300
Maximum ESP
Pa 620 710
1RPLQDO$LUÀRZ
m³/s 2.5 3.3
Fan Power Input (Fan Gain)
(2) kW 0.85 2.6
Connections
Water Inlet / Outlet -
mm 42 54
Condensate Drain Hose
mm 22 22
Filtration
'LVSRVDEOHWR%6(1*
Quantity
6 6
Electric Heating (Total)
kW 15 15
+XPLGL¿HU
Capacity
kg/hr 8 15
Drain Pump Flow Rate
l/m 7 7
Feed / Drain
´%63)%UDLGHG)OH[LEOH+RVHPP+RVH&RQQHFWLRQ
Hot Water Condensate Pump
Head
m 5 5
Flow
l/m 10.8 10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m 4 4
Flow
l/m 1.7 1.7
Drain
PP4XDUWHU7XUQ3ODVWLFµ%DUE¶&RQQHFWLRQ
Upgraded Fan Motor - EC Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Quantity x Motor Size
(4) kW 2 x 3.6 N/A
Speed @ 25Pa / Maximum ESP
rpm 1170 / 2300 N/A
Maximum ESP
Pa 1090 N/A
Fan Power Input (Fan Gain)
(2) kW 0.98 N/A
'RZQÀRZ&KLOOHG:DWHU
Mechanical Data
SC15D035 - SC15D060
SmartCool™ 16 - 60
Precision Air Conditioning
78 SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical
DF
C000
