AIREDALE R410A - Downflow Direct Expansion Mechanical Data (SC12 D033-SC12 D036)

SC12D033-X200-0 SC12D036-X200-0
Standard Condenser Match
1 x CR65 1 x CR65
Capacity
Nom Cooling (Gross)
(1) kW 36.04 39.88
Capacity Steps
2 2
Dimensions – W x D x H
mm 1200 x 890 x 1980 1200 x 890 x 1980
Weight – Machine / Operating
(3) kg 410 / 420 410 / 420
Construction
3DQHOV*DOYDQLVHG6KHHW6WHHO(SR[\%DNHG3RZGHU3DLQW±%ODFN*UH\5$/
Material / Colour
Frame: Anodised Aluminium Frame with aluminium corners, Epoxy
EDNHG3RZGHU&RDWHG3DLQW%ODFN*UH\5$/
Evaporator
5LÀHG&RSSHU7XEH7XUEXODWHG+\GURSKLOLF&RDWHG$OXPLQLXP)LQV
Cooling/Dehum Stages
2 / 2 2 / 2
Fan Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Motor Type
EC EC
Quantity x Motor Size
(4) kW 1 x 3.1 1 x 3.1
Speed @25Pa / Maximum ESP
rpm 1300 / 1560 1300 / 1560
Maximum ESP
Pa 360 360
1RPLQDO$LUÀRZ
m³/s 2.5 2.5
Fan Power Input (Fan Gain)
(2) kW 1.53 1.53
Compressor – Scroll
&RQ¿JXUDWLRQ
Single Circuit – Tandem Compressors
Quantity
2 2
Oil Charge Volume
l 2 x 1.8 2 x 1.8
Oil Type
POE
Refrigeration
Single Circuit
Refrigerant Control and Type
Electronic Expansion Valve
Refrigerant Type
R410A
Holding Charge
Inert Gas
Charge (per circuit)
(5) kg 3.2 3.2
Connections
Liquid (sweat)
in 5/8 5/8
Discharge (sweat)
in 7/8 7/8
Condensate Drain Hose
mm 22 22
Filtration
'LVSRVDEOHWR%6(1*
Quantity
6 6
Electric Heating (Total)
kW 7.5 7.5
+XPLGL¿HU
Capacity
kg/hr 8 8
Drain Pump Flow Rate
l/m 7 7
Feed / Drain
´%63)%UDLGHG)OH[LEOH+RVHPP+RVH&RQQHFWLRQ
Hot Water Condensate Pump
Head
m 5 5
Flow
l/m 10.8 10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m 4 4
Flow
l/m 1.7 1.7
Drain
PP4XDUWHU7XUQ3ODVWLFµ%DUE¶&RQQHFWLRQ
Upgrade Fan Motor - EC Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Quantity x Motor Size
(4) kW 1 x 3.5 1 x 3.5
Speed @ 25Pa / Maximum ESP
rpm 1320 / 1620 1320 / 1620
Maximum ESP
Pa 450 450
Fan Power Input (Fan Gain)
(2) kW 1.61 1.61
'RZQÀRZ'LUHFW([SDQVLRQ
Mechanical Data
SC12D033 - SC12D036
SmartCool™ 16 - 60
Precision Air Conditioning
56 SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical
X-Type DF
