AIREDALE R410A - Downflow Direct Expansion Mechanical Data (SC15 D027-SC15 D035)

SC15D027-X200-0 SC15D030-X200-0 SC15D035-X200-0
Standard Condenser Match
1 x CR30 1 x CR50 1 x CR50
Capacity
Nom Cooling (Gross)
(1) kW 27.53 32.84 37.47
Capacity Steps
2 2 2
Dimensions – W x D x H
mm 1500 x 890 x 1980 1500 x 890 x 1980 1500 x 890 x 1980
Weight – Machine / Operating
(3) kg 460 / 460 470 / 470 470 / 470
Construction
3DQHOV*DOYDQLVHG6KHHW6WHHO(SR[\%DNHG3RZGHU3DLQW±%ODFN*UH\5$/
Material/Colour
Frame: Anodised Aluminium Frame with aluminium corners, Epoxy
EDNHG3RZGHU&RDWHG3DLQW%ODFN*UH\5$/
Evaporator
5LÀHG&RSSHU7XEH7XUEXODWHG+\GURSKLOLF&RDWHG$OXPLQLXP)LQV
Cooling/Dehum Stages
2 / 2 2 / 2 2 / 2
Fan Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Motor Type
EC EC EC
Quantity x Motor Size
(4) kW 2 x 1.7 2 x 1.7 2 x 1.7
Speed @25Pa / Maximum ESP
rpm 1160 / 1770 1330 / 1770 1540 / 1770
Maximum ESP
Pa 610 500 320
1RPLQDO$LUÀRZ
m³/s 2.4 2.8 3.3
Fan Power Input (Fan Gain)
(2) kW 0.88 1.28 1.97
Compressor – Scroll
&RQ¿JXUDWLRQ
Single Circuit – Tandem Compressors
Quantity
2 2 2
Oil Charge Volume
l 2 x 1.2 2 x 1.7 2 x 1.8
Oil Type
POE
Refrigeration
Single Circuit
Refrigerant Control and Type
Electronic Expansion Valve
Refrigerant Type
R410A
Holding Charge
Inert Gas
Charge (per circuit)
(5) kg 3.7 3.8 4.0
Connections
Liquid (sweat)
in 1/2 1/2 5/8
Discharge (sweat)
in 5/8 7/8 7/8
Condensate Drain Hose
mm 22 22 22
Filtration
'LVSRVDEOHWR%6(1*
Quantity
6 6 6
Electric Heating (Total)
kW 15 15 15
+XPLGL¿HU
Capacity
kg/hr 3 3 3
Drain Pump Flow Rate
l/m 7 7 7
Feed / Drain
´%63)%UDLGHG)OH[LEOH+RVHPP+RVH&RQQHFWLRQ
Hot Water Condensate Pump
Head
m 5 5 5
Flow
l/m 10.8 10.8 10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m 4 4 4
Flow
l/m 1.7 1.7 1.7
Drain
PP4XDUWHU7XUQ3ODVWLFµ%DUE¶&RQQHFWLRQ
Upgrade Fan Motor - EC Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Quantity x Motor Size
(4) kW 2 x 3.6 2 x 3.6 2 x 3.6
Speed @ 25Pa / Maximum ESP
rpm 1170 / 2300 1340 / 2300 1550 / 2300
Maximum ESP
Pa 1070 970 820
Fan Power Input (Fan Gain)
(2) kW 1.00 1.41 2.12
'RZQÀRZ'LUHFW([SDQVLRQ
Mechanical Data
SC15D027 - SC15D035
SmartCool™ 16 - 60
Precision Air Conditioning
58 SmartCool Technical Manual 7525371 V1.2.0_03_2013
