AIREDALE R410A - Downflow Chilled Water Mechanical Data (SC12 D025-SC12 D045)

SC12D025-C000-0 SC12D045-C000-0
Capacity
Nom Cooling (Gross)
(1) kW 24.9 39.9
Dimensions - W x D x H
mm 1200 x 890 x 1980 1200 x 890 x 1980
Weight - Machine / Operating
(3) kg 320 / 340 340 / 360
Construction
3DQHOV*DOYDQLVHG6KHHW6WHHO(SR[\%DNHG3RZGHU3DLQW%ODFN*UH\5$/
Material/Colour
Frame: Anodised Aluminium Frame with aluminium corners, Epoxy
EDNHG3RZGHU&RDWHG3DLQW%ODFN*UH\5$/
Cooling Coil
Copper Tube/Turbulated Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water Volume
l 21.21 27.20
Water Flow Rate
l/s 1.19 1.9
Pressure Drop
kPa 25.3 33.15
Fan & Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Motor Type
EC EC
Quantity x Motor Size
(4) kW 1 x 1.5 1 x 3.1
Speed @25Pa ESP / Maximum ESP
rpm 900 / 1230 1380 / 1560
Maximum ESP
Pa 320 270
1RPLQDO$LUÀRZ
m³/s 1.7 2.5
Fan Power Input (Fan Gain)
(2) kW 0.53 1.85
Connections
Water Inlet / Outlet -
mm 42 42
Condensate Drain Hose
mm 22 22
Filtration
'LVSRVDEOHWR%6(1*
Quantity
6 6
Electric Heating (Total)
kW 7.5 7.5
+XPLGL¿HU
Capacity
kg/hr 8 8
Drain Pump Flow Rate
l/m 7 7
Feed / Drain
´%63)%UDLGHG)OH[LEOH+RVHPP+RVH&RQQHFWLRQ
Hot Water Condensate Pump
Head
m 5 5
Flow
l/m 10.8 10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m 4 4
Flow
l/m 1.7 1.7
Drain
PP4XDUWHU7XUQ3ODVWLFµ%DUE¶&RQQHFWLRQ
Upgraded Fan Motor - EC Motor
%DFNZDUGV&XUYHG&HQWULIXJDO'LUHFW'ULYH
Quantity x Motor Size
(4) kW 1 x 3.1 1 x 3.5
Speed @ 25Pa / Maximum ESP
rpm 910 / 1560 1390 / 1620
Maximum ESP
Pa 700 360
Fan Power Input (Fan Gain)
(2) kW 0.53 1.94
'RZQÀRZ&KLOOHG:DWHU
Mechanical Data
SC12D025 - SC12D045
SmartCool™ 16 - 60
Precision Air Conditioning
76 SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical
DF
C000
