AIREDALE R410A - Downflow Direct Expansion Performance Data; Performance Data Tables (X100;X200;X1 X1); Unit Operating Limits

'RZQÀRZ'LUHFW([SDQVLRQ
Performance Data
X100 / X200 / X1X1
Ambient Temperature (°C)
Model
Air On 25 30 35 40 46
Temp. (°C) TC SC TC SC TC SC TC SC TC SC
/ %RH (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW) (kW)
SC09D016-X100-0 22 / 50 16.7 16.3 16.7 16.3 16.6 16.1 15.9 15.4 14.9 14.5
1 x CR30 24 / 45 17.6 17.5 17.6 17.5 17.4 17.3 16.7 16.6 15.7 15.6
26 / 40 18.5 18.5 18.5 18.5 18.3 18.3 17.5 17.5 16.5 16.5
SC09D019-X100-0 22 / 50 20.3 19.2 19.6 18.8 18.7 18.2 17.9 17.4 16.8 16.3
1 x CR30 24 / 45 21.1 21.0 20.4 20.3 19.6 19.5 18.8 18.6 17.6 17.5
26 / 40 22.1 22.1 21.4 21.4 20.5 20.5 19.6 19.6 18.5 18.5
SC09D023-X100-0 22 / 50 24.3 22.0 24.1 21.9 23.1 21.3 22.0 20.6 20.7 19.7
1 x CR50 24 / 45 24.9 24.6 24.6 24.5 23.7 23.6 22.8 22.6 21.6 21.4
26 / 40 26.0 26.0 25.7 25.7 24.8 24.8 23.8 23.8 22.6 22.6
SC09D026-X100-0 22 / 50 27.1 23.1 26.7 22.9 25.6 22.6 24.5 22.2 23.0 21.2
1 x CR50 24 / 45 27.9 25.7 27.4 25.5 26.2 25.1 25.1 24.7 23.7 23.6
26 / 40 28.7 28.4 28.2 28.1 27.1 27.1 26.1 26.1 24.7 24.7
SC12D020-X200-0 22 / 50 23.1 22.4 22.1 21.5 21.0 20.4 19.9 19.3 18.4 17.9
1 x CR30 24 / 45 23.6 23.5 22.7 22.6 21.7 21.6 20.7 20.6 19.3 19.2
26 / 40 24.5 24.5 23.7 23.7 22.7 22.7 21.7 21.7 20.3 20.3
SC12D023-X200-0 22 / 50 29.1 27.2 28.4 27.0 27.0 26.3 25.7 25.0 24.0 23.3
1 x CR50 24 / 45 29.9 28.9 29.2 28.5 27.8 27.6 26.6 26.4 25.0 24.8
26 / 40 30.9 30.9 30.2 30.2 29.1 29.1 27.8 27.8 26.2 26.2
SC12D029-X200-0 22 / 50 32.4 29.5 31.4 29.2 29.9 28.7 28.5 27.7 26.6 25.9
1 x CR50 24 / 45 33.4 31.7 32.3 31.1 30.8 30.4 29.4 29.3 27.7 27.6
26 / 40 34.4 34.4 33.4 33.4 32.1 32.1 30.8 30.8 29.1 29.1
SC12D033-X200-0 22 / 50 37.3 32.3 36.7 32.1 35.0 31.6 33.3 31.0 31.1 30.2
1 x CR65 24 / 45 38.5 35.3 37.7 34.9 36.0 34.1 34.3 33.2 32.1 31.9
26 / 40 39.6 38.8 38.8 38.3 37.1 37.1 35.5 35.5 33.6 33.6
SC12D036-X200-0 22 / 50 41.7 33.7 40.6 33.3 38.8 32.8 36.9 32.2 34.5 31.4
1 x CR65 24 / 45 42.9 37.5 41.7 36.9 39.9 36.0 38.0 35.0 35.6 33.8
26 / 40 44.0 41.3 42.7 40.6 41.0 39.6 39.1 38.5 36.7 36.7
SC15D027-X200-0 22 / 50 29.3 24.5 27.9 26.5 26.4 25.5 25.0 24.3 23.3 22.6
1 x CR30 24 / 45 30.3 30.1 28.9 28.7 27.5 27.4 26.1 26.0 24.4 24.2
26 / 40 31.4 31.4 30.1 30.1 28.8 28.8 27.3 27.3 25.5 25.5
TC = Total Cooling
SC = Sensible Cooling
THR = Total Heat Rejection
(1) All data quoted is gross
'HGXFWIDQPRWRUJDLQIRUQHWWGXWLHVUHIHUWR0HFKDQLFDO'DWDVHFWLRQ
Operating Limits
Indoor Air Temperature +18°C to +28°C
,QGRRU5+WR%DVHGXSRQ&'U\%XOE
Outdoor Temperature -20°C to +46°C
