AIREDALE R410A - Downflow Direct Expansion Electrical Data (SC18 D048-SC15 D055)

'RZQÀRZ'LUHFW([SDQVLRQ
Electrical Data
SC18D048 - SC15D055
SC18D048-X1X1-0 SC18D055-X1X1-0
Unit Data Full Function - X
Nominal Run Amps
(1) A 53.7 58.1
Maximum Start Amps
A 150.3 159.5
Recommended Mains Fuse Size
A 63 80
Unit Data Cooling Only - X
Nominal Run Amps
(2) A 45 49.4
Maximum Start Amps
A 141.6 150.8
Recommended Mains Fuse Size
A 50 63
Max Mains Incoming Cable Size
mm² 35 35
Mains Supply
V 400V / 3PH + N / 50HZ
Control Circuit
VAC 24 24
Evaporator Fan - Motor Per Fan
Motor Type
(3) kW EC EC
Quantity x Motor Size
2 x 3.1 2 x 3.1
Full Load Amps
5 5
Locked Rotor Amps
5 5
Compressor - Per Compressor
Quantity x Motor Size
kW 2 x 7.82 2 x 9.11
Nominal Run Amps
A 14.37 16.58
Locked Rotor Amps
A 118 118
Type of Start
Direct On Line
Standard Condenser Match - AC Motor - Per Fan
Quantity x Motor Size
kW 2 x 0.6 2 x 0.6
Full Load Amps
A 2.62 2.62
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
2 2
Number of Elements
6 6
Rating
kW 15 15
Current per Phase
A 21.65 21.65
+XPLGL¿HU
Capacity
kg/hr 8 8
Rating
kW 6 6
Full Load Amps
A 8.7 8.7
First upgrade EC Motor - Per Fan
Quantity x Motor Size
(3) kW 2 x 3.5 2 x 3.5
Full Load Amps
A 5.7 5.7
Locked Rotor Amps
A 5.7 5.7
Standard Condenser Motor - EC Motor - Per Fan
Quantity x Motor Size
kW 2 x 0.73 2 x 0.73
Full Load Amps
A 3.3 3.3
Mechanical
(QWHULQJDLU&5+DPELHQW&
)DQ*DLQ)DQSRZHULQSXWEDVHGXSRQIDQRSHUDWLQJZLWKGHVLJQDLUÀRZDW3D(63WKHVHYDOXHVPD\FKDQJHZLWKGLIIHUHQW(63
(3) Machine weight excludes a refrigerant charge For refrigerant charges, refer to Unit Refrigerant Charge (kg/circuit).
%DFNZDUGFXUYHG(&IDQRSWLRQVTXRWHHOHFWULFDOSRZHU$OORWKHURSWLRQVTXRWHVKDIWSRZHU
(5) For refrigerant charges, refer to Unit Refrigerant Charge (kg/circuit)
Electrical
9DOXHVJLYHQIRUIXQFWLRQXQLWVZLWKVWDQGDUGVHOHFWLRQVIRUKHDWLQJKXPLGL¿FDWLRQVXSSO\DLUIDQVDQGPDWFKHGFRQGHQVHU
at 7°C evaporating and 54.4°C condensing
(2) Values given for Cooling only units incl. evaporator fan for optional data, please contact Airedale.
(3) Electrical input power relates to the maximum absorbed electrical power. Actual operating fan power input is shown in the mechanical data tables
Precision Air Conditioning SmartCool™ 16 - 60
65
SmartCool Technical Manual 7525371 V1.2.0_03_2013
Technical X-TypeDF
