Interior
2020 Flying Cloud 5-13
High Volume Roof Vent
The high-volume roof vent system is designed to
quickly exhaust stale, hot air and draw in fresh air� It
is great to use when the outside temperature does not
call for air conditioning, but heat has built up in your
trailer�
The core of the system is a powerful rotary fan that
works with a slightly open window to create a balanced
airow. It is designed for maximum air exchange,
minimum sound levels and power consumption� Fresh,
clean, natural air is pulled in� Hot, stale, stuffy air is
pushed out�
NOTE
Never place Lindeen™ or a like cover over ceiling
fan. Greatly restricted airow and increased sound
levels will occur.
Operation
1� Open dome approximately 3 in� or more (ceiling fan
has a built-in safety switch that will not allow motor
to operate unless dome is partially open)�
2� Turn 3-speed knob to desired performance level
(3-Low, 2-Medium, 1-High, O-Off)�
3� Open window(s) or door for airow.
The source of airow is determined by the number of
window(s) or door opened� For best results, close all
roof vents and open one window that is the greatest
distance from the ceiling fan�
NOTE
For maximum airow, do not close vent shade, if
equipped, while using Exhaust Fan.
cords and adapters whenever possible� If an extension
cord must be used, it should be as short and heavy as
possible to provide the most current�
If high temperatures are expected, make an effort to
park in a shaded area� Starting the air conditioner
early in the morning also helps. It is more efcient to
hold a comfortable temperature than it is to lower the
temperature after the interior of the trailer is already
hot�
Never run your air conditioner with the vents closed�
Doing so could cause the air conditioner to freeze
and may damage to the unit� The manufacturer
recommends having at least 3 vents open when
running to prevent any chance of freezing up
Heat Pump
Your air conditioner has a built in heat pump designed
to take the chill out of the air. To operate, tap “heat
pump” for the desired zone on the Multiplex panels
climate control screen� The heat pump will run until the
current temperature reaches the set temperature and
then shut off�
NOTE
Review the air conditioning literature supplied in
your owner’s packet before proceeding.
NOTE
It is recommended to clean lters Weekly when A/C
is in full use.
Exhaust Fans
In the bathrooms round ventilators are used and are
opened by pushing straight up on the crossbar handle
and pressing the red switch to engage the fan motor�
NOTE
The range exhaust cover on the outside of the
trailer has a swinging door that can be latched
during inclement weather and should be latched
while in travel. When operating the exhaust fan, the
latches should be turned so the door swings open
when the fan is on.
