6. Wiring Diagrams

• All AC Units must be initialised with Standard AC Wall Controller connected

to AC Indoor Unit to complete necessary eld settings and conrm the AC

runs normally

• Turn OFF power and disconnect Standard AC Wall Controller from AC Indoor

Unit if it’s not going to be used.

• Refer to relevant AC Gateway Drawings below to connect Gateway.

• Refer to Dip Switch settings (if applicable) on the Gateway Drawings below.

• After completing wiring and setting the dip switches, turn power ON.

AC Indoor, Gateway and AirTouch 2+ can be powered up at the same time,

but power up AC Indoor and Gateway no later than the AirTouch 2+.
