1. Beware of the dierent dip switch settings for rmware before 2.0 and after
2.0 (including 2.0)
2. Wire AirTouch 2+, gateway and AC indoor as per diagram below and leave the
dipswitches on the gateway at their default position. Make sure all wires are
connected properly.
3. Initialise the AC Unit with ME AC Wall Controller connected.
4. Remove the ME wall controller if it is not to be used after commissioning. Make
sure the AC control temperature is measured from the indoor unit return air.
5. Go to AC Setup and select the proper temperature sensor for AC control.
(
657215
)
Commissioning notes
Wiring Diagrams contd.
