Selecting the Interface
Type
A beam illuminates the label. The projected pattern of the
aiming system will be smaller when the reader is closer to the
bar code and larger when it is farther from the code.
Symbologies with smaller bars or elements (mil size) should
be read closer to the unit. Symbologies with larger bars or
elements (mil size) should be read farther from the unit.
If the aiming system is centered you will get a good read.
Successful reading is signaled by an audible tone plus a
goodread green spot LED indicator.
Reference the S2 Product Reference Guide (PRG) on the
AirTrack website for more information about this feature
and other programmable settings.
Selecting the Interface Type
Upon completing the physical connection between the
reader and its host, proceed directly to Interface Selection
below for information and programming for the interface
type the reader is connected to (for example: RS-232,
Keyboard Wedge, USB, etc.) and scan the appropriate bar
code to select your system’s correct interface type.
Interface Selection
The reader model will support one of the following sets
of host interfaces:
General Purpose Models —
RS-232, RS-232 OPOS,
USB, Keyboard Wedge.
Retail Point of Sale Models —
RS-232, RS-232 OPOS,
USB. Information and programming options for each
interface type are provided in this section. For defaults and
additional information associated with each interface,
proceed to the corresponding chapter in the S2 PRG.
