Reading
Parameters
Reading Parameters
Move the reader toward the target and center the aiming
pattern and illumination system to capture and decode
the
image. See Using the S2 on page 3 for more information.
The aiming system will briefly switch off after the acquisition
time, and if no code is decoded will switch on again before the
next acquisition. The illuminator will remain on until the
symbol is decoded.
As you read code symbols, adjust the distance at which
you are holding the reader.
Aiming System
A number of options for customizing control of the Aiming
System are available. See the S2 PRG for more
information and programming bar codes.
Good Read Green Spot Duration
Successful reading can be signaled by a good read green
spot. Use the bar codes that follow to specify the duration of
the good read pointer beam after a good read.
GOOD READ GREEN SPOT DURATION
ENTER/EXIT PROGRAMMING MODE
Disabled
♦
Short (300
ms)
Medium (500
ms)
Long (800
ms)
