AirTrack S2 - Programming Mode Indications; Programming Mode Entry; Programming Mode Label Rejection; Programming Mode Partial Label Acceptance

24
S2
LED and Beeper Indications
Indicator
Description
LED
Beeper
Limited Scanning
Label Read
Indicates that a host
connection is not
established.
N/A
Reader 'chirps' six
times at the highest
frequency and current
volume.
Reader Active Mode
The reader is active and
ready to scan.
The LED is lit
steadily
a
N/A
Reader
Disabled
The reader has been
disabled by the host.
The LED blinks
continuously
N/A
Green Spot
a
flashes
momentarily
Upon successful read of
a label, the software
shall turn the green spot
on for the time specified
by the config ured
value.
N/A
N/A
a
Except when in sleep mode or when a Good Read LED Duration other than 00 is
selected
Programming Mode
The following indications ONLY occur when the reader is in
Programming Mode.
Indicator
Description
LED
Beeper
Indicator
Description
LED
Beeper
Label Programming
Mode Entry
A valid programming label
has been scanned.
LED blinks
continuousl
y
Reader sounds four
low frequency beeps.
Label Programming
Mode Rejection of
Label
A label has been rejected.
N/A
Reader sounds three
times at lowest
fre quency and
current volume.
Label Programming
Mode Acceptance of
Partial Label
In cases where multiple
labels must be scanned to
program one feature, this
indication acknowledges
each portion as it is
suc cessfully scanned.
N/A
Reader sounds one
short beep at highest
frequency and cur rent
volume.
