AirTrack S2 - Technical Specifications

20
S2
Technical Specifications
Multiple Label Reading
The reader offers a number of options for multiple label
reading. See the PRG or software configuration tool for
descriptions of these features and programming labels.
Technical Specifications
The following table contains Physical and Performance
Characteristics, User Environment and Regulatory
information.
Item
Description
Physical C har ac teri s t ic s
Color
Black & white
Dimensions
Height
6.4"/163 mm
Length 3.6"/91 mm
Width 1.6"/41 mm
Weight (without cable)
Approximately 5.1 ounces/145 g
Electrical Cha rac t e ris t i cs
Voltage & Cur r ent
Input Voltage: 4.5 - 14.0VDC
Operating (typical): 140mA
Operating (max): 380mA
Idle/standby (typical): 50mA
Performance C ha r a c t e r i s t i cs
Light Source
LEDs
Roll (Tilt) Tolerance
Up to ± 360°
Pitch Tolerance
± 65°
Skew (Yaw) Tolerance
± 60°
Print Contrast Minimum
25% minimum reflectance
