Leakage detection
1. Remove the valve caps on
the liquid valve and gas
valve and the nut of refri-
gerant charging vent.
Connect the charging ho-2.
se of piezometer to the
refrigerant charging vent
3.
of gas valve and then co-
nnect the other charging
hose to the vacuum pump.
4.
mains in -0.1MPa.
Close the vacuum pump
Open the piezometer com-
pletely and operate for
10-15min to check if the
pressure of piezometer re-
in -0.1MPa. If the pressure decreases, there may be leakage.
6.
and maintain this status for
1-2min to check if the pres-
sure of piezometer remains
Tighten the screw caps of valves and refrigerant charging vent.
5. Remove the piezometer, open the valve core of liquid valve and gas valve
liquid valve
completely with inner hexagon spanner.
gas valve
Vacuum pumping
Use vacuum pump
refrigerant charging
vent
vacuum pump
nut of refrigerant
charging vent
piezometer
valve cap
Lo Hi
inner hexagon
spanner
open
close
1.
2.
With leakage detector:
Reinstall the handle.7.
Check if there is leakage with leakage detector.
With soap water:
If leakage detector is not available, please use soap water for leakage detection.
Apply soap water at the suspected position and keep the soap water for more
than 3min. If there are air bubbles coming out of this position, there's a leakage.
