Model Indoor Unit AWAU-HDDE024-N11
Model Outdoor Unit AWAU-YDDE024-H11
Installation Method of Pipe Flared
Characteristics Units Cooling
Heating
Avera
g
e Warmer
Capacity
(1)
kW 6,45 (2,53-6,55) 7,0 (2,53-7,6)
Pdesign kW 6,45 5,8 6,2
SEER / SCOP
(2)
W/W 5,4 3,8 4,6
Energy efficiency class A
A
A++
Annual energy consumption kWh 439 2137 1852
Tbiv
o
C N/A -7 ??
Tol
o
C N/A -15 -10
Power supply V/Ph/Hz 220-240V/Single/50Hz
Circuit breaker rating A 25
Fan type & quantity Cross flow fan x1
Fan speeds H/M/L RPM 1350/1150/950/850 1400/1200/1000/900
Air flow
(3)
H/M/L m3/hr 1000/800/700/550 1000/800/700/550
External static
pressure
Min-Max Pa 0
Sound power level
(4)
H/M/L dB(A) 63/57/52/49
Sound pressure level
(5)
H/M/L dB(A) 51/47/42/39
Moisture removal l/hr 2
Condensate drain tube I.D mm 16
Dimensions WxHxD mm 1008X319X221
Weight kg 14,5
Package dimensions WxHxD mm 1076X328 X398
Packaged weight kg 17,5
Units per pallet units 18 units per pallet
Stacking height units
6 levels
Refrigerant control Capillary
Compressor type, model Twin Rotary DC Inverter
Fan type & quantity Axial x 1
Fan speeds H/L RPM
Air flow H/L m3/hr 4000
Sound power level
(4)
H/L dB(A) 68
Sound pressure level
(5)
H/L dB(A) 58
Dimensions WxHxD mm 980X790X427
Weight kg 55,5
Package dimensions WxHxD mm 1083X488X855
Packaged weight kg 60,5
Units per pallet Units 6 units per pallet
Stacking height
units 2 levels
Refrigerant type
R410A
Refrigerant charge (standard connecting
tubing length)
kg(5m) 1.8
Additional charge per 1 meter gr / 1m 5m<L<25m 50g/m
Liquid line In.(mm) 1/4"(6.35)
Connections
between units
Suction line In.(mm) 5/8"(15.88)
Max.tubing length m. Max.25
Max.height difference m. Max.10
Operation control type Remote control
Heating elements kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2) SEER / SCOP calculation accordance with EN14825.
