2. PRODUCT DATA SHEET
Model Indoor Unit
AWAU-HDDE009-N11
Model Outdoor Unit
AWAU-YDDE009-H11
Installation Method of Pipe
F lared
Characteristics
Units
Cooling
Heatin g
Average
Warmer
Capacity
(1)
kW
2,6 (0,45-3,23)
3,0 (0,45-4,1)
Pdesign
kW
2,6
2,6
2,8
SEER / SCOP
(2)
W/W
5,6
3,8
4,4
Energy efficiency class
A+
A
A+
Annual energy consumption
kWh
163
958
891
Tbiv
o
C
N/A
-7
??
Tol
o
C
N/A
-15
-10
Power supply
V/Ph/Hz
220-240V/Single/50Hz
Circuit breaker rating
A
16
INDOOR
Fan type & quantity
Cross flow fan x1
Fan speeds
H/M/L
RPM
1350/1100/900/700
1350/1140/980/820
Air flow
(3)
H/M/L
m3/hr
600/520/370/280
600/520/370/280
External static
pressure
Min-Max
Pa
0
Sound power level
(4)
H/M/L
dB(A)
55/48/40/34
Sound pressure level
(5)
H/M/L
dB(A)
43/38/30/24
Moisture removal
l/hr
0,8
Condensate drain tube I.D
mm
16
Dimensions
WxHxD
mm
770x283x201
Weight
kg
8
Package dimensions
WxHxD
mm
855x280x360
Packaged weight
kg
11
Units per pallet
units
21 units per pallet
Stacking height
units
7 levels
OUTDOOR
Refrigerant control
EEV
Compressor type, model
Rotary DC Inverter
Fan type & quantity
Axial x 1
Fan speeds
H/L
RPM
850
Air flow
H/L
m3/hr
1800
Sound power level
(4)
H/L
dB(A)
62
Sound pressure level
(5)
H/L
dB(A)
51
Dimensions
WxHxD
mm
776x540x320
Weight
kg
36
Package dimensions
WxHxD
mm
851x595 x363
Packaged weight
kg
41
Units per pallet
Units
9 units per palle t
Stacking height
units
3 levels
Refrigerant type
R410 A
Refrigerant charge (standard connecting
tubing length)
kg(5m)
0.8
Additional charge per 1 meter
gr / 1m
5m<L<15m 20g/m
Connections
between units
Liquid line
In.(mm)
1/4"(6.35)
Suction line
In.(mm)
3/8"(9.53)
Max.tubing length
m.
Max . 15
Max.height difference
m.
Max.10
Operation control type
Remote control
Heating elements
kW
Others
(1) Rating conditions in accordance with ISO 5151 and ISO 13253 (for ducted units).
(2) SEER / SCOP calculation accordance with EN14825.
