EXPLODED VIEWS AND SPARE PARTS LISTS
SM PNXDCI 1-A.1 GB
14.2 Indoor Unit: PNX 9 DCI
No. PN Description Quantity
1 465800016 A Grill A Assy./ Electra PNX 7/9/12/14 1
2 4518655 Air filter 2
3 4519132 ACTIVE CARBON FILTER ASSY 1
4 4519744 Low temperature catalys 1
5 465720059 Front Frame Assy./ PNX7/9/12/14 1
6 4526952 Screw Cover 2
7 4526389 R410A EVAPORATOR ASSY HPI DC 1
8 4518664 Drain hose 1
9 4527434 Air Outlet Assy 1
10 4518638 Upper Louver 1
11 4526953 Lower Louver 1
12 4518640 Vert. Louver A 2
13 4518641 Vert. Louver B 10
14 4518662 Bearing assy fan 1
15 4518661 Fan assy plastic D91 1
16 4518730 Rear panel assy 1
17 4518670 Installation Plate 1
18 4518654 TUBE BRACKET 1
19 4519864R PG 20W PG Motor 1
20 4518650 Motor Cover 1
21 452969400 Step Motor A 1
22 452969500 Step Motor B 1
23 455013705R PowerCordWithoutPlug/3G/1.5/2100() 1
24 4519147 Power Cord Clip 1
25 467300079R DisplayBoardAssy./PNX25/35DCIWithnewfunc 1
26 4518666 Sensor Braket 1
27 467300067R PNX DCI Indoor Controller With Vertical 1
28 438082 Thermistor Indoor 1
29 467400024 Indoor Air Inlet Temperature 320mm 1
30 465340012 Terminal Cover 1
31 4518663 ELECTROSTATIC FLITER WNG-1 1
32 467200004R RC-3I-1 KUMANDA 1
33 4518651 Cover Side Motor 1
34 4518682 Gear BOX ASSY 1
34 452867800R Transformer/WNG DCI 1
35 4518646 LOUVER SUPPORT 1
37 4518657 TUBE LOCK 1
38 4518656 MOUNTING HOOK 2
39 4519900 IONIZER CABLE A 1
40 467430000 Power Supply Unit /Ionizer 1
41 467480001 Ionizer/WNG NWNG SERIES 1
42 465160004 A Air Inlet Frame A 1
