INTRODUCTION
Airzone systems enable the management of Master and Zone interfaces. Master thermostats enable mode management or
define the efficiency level with the Eco-Adapt function.
It is recommended to use of a Blueface thermostat as Master Interface, this enables time schedule management and more
unique functionalities.
Remember: This system has to admits one single Master thermostat.
To distinguish a Master Interface from a Zone Interface, check the next points.
- Blueface Master: Mode, Eco-Adapt and Speed* icons shown in white color.
- Blueface Zone: Mode, Eco-Adapt and Speed* icons shown in gray color.
- Think Master: Accessing the settings menu, Operation Mode and Speed* are available.
- Think Zone: Accessing the settings menu, Operation mode and Speed* are unavailable.
*Note: Only available in installations with Fancoil.
SYSTEM INSTALLATION
Before the Airzone system commissioning, please check:
The system is going to control works correctly without the Airzone system installed.
In direct expansion unit systems, the indoor unit wired thermostat has been installed.
In order to install the Airzone system, carefully follow these steps:
Connect all the necessary elements (see section Assembly and connection).
- Connect the actuators.
- Connect the communication gateway.
- Connect all the elements of the system (thermostats, modules, etc.).
- Power the main board.
Check all the assembly and the connection are correct (see section Assembly and connection evaluation).
Configure the system.
- Configure all the thermostats (see sections Initial configuration and Advanced settings).
If you have any other doubt, check the user and installation manuals.
Access all our technical documents and the self-diagnosis section, check the most FAQs,
certificates, watch our videos and read our declaration of conformity at:
myzone.airzone.es/productos/
