Airzone Flexa - Assembly and Connection Diagrams; Surface and Embedded Assembly; Kit and Motor Connection Diagrams


11
Fig. 7 - Montaje en superficie / Montage en surface /
Montaggio in superficie / Surface assembly
Fig. 8 - Montaje empotrado / Montage encastré /
Montaggio encassato / Embedded assembly
Fig. 9 – Conexión Kit Amperimétrico / Connexion Kit ampérométrique / Collegamento Kit Amperimetrico
/ Amperometric Connection Kit
Fig. 10 – Conexión medidor de consumo / Connexions compteur de consommation /
Collegamento sensore di corrente / Current-meter Connection
