REFERENCIAS/ RÉFÉRENCES/ REFERENZE/ REFERENCIES
Fig. 1 - Esquema general de conexión sistema Flexa/ Schéma de Connexion général Flexa/ Impianto di
connesione generale/ General Connection Scheme
Fig. 2 - Central de Sistema Flexa/ Central de système Flexa/ Scheda di sistema Flexa/ Flexa Main Board
Nº
Descripción/ Description/ Descrizione/ Description
1
Transformador / Transformateur
/ Trasformatore / Transformer (230Vac/12Vcc)
2
Conexión de alimentación / Connecteur d’alimentation / Connettore di alimentazione / Mains
connection
3
D11: LED de alimentación (rojo) / LED Alimentation (rouge) / LED Alimentazione (rosso) / Mains
1
2 4 5 6 7 8
10
1215 16 17 18 19
20
3
9
11
14 13
