SPECIFICATIONS
RADIO SECTION
(FM)
Frequency Range: 87.5 MHz – 108 MHz
(100-kHz steps)*
87.5 MHz – 108 MHz
(50-kHz steps)*
Usable Sensitivity: 12.7 dBf
50 dB Quieting Sensitivity:
17.2 dBf
IF Rejection: 80 dB
Frequency Response: 30 Hz – 15,000 Hz
S/N Ratio: 63 dB
Stereo Separation: 35 dB at 1 kHz
Alternate Channel Selectivity:
70 dB
Capture Ratio: 3 dB
(AM)
Frequency Range: 530 kHz – 1,710 kHz
(10-kHz steps)*
531 kHz – 1,602 kHz
(9-kHz steps)*
Usable Sensitivity: 30 µV (30 dB)
* Set the frequency increment for your area using
the switch on the bottom of the unit.
(The switch is set at the factory to the 10k position [for
the U.S.A.])
CD SECTION
Frequency Response: 17 Hz–20 kHz +0/–3 dB
Dynamic Range: More than 80 dB
Channel Separation: More than 65 dB
S/N Ratio: More than 85 dB
Wow/Flutter: Unmeasurable
MP3 decoding: MPEG 1 Audio Layer 3
AUDIO SECTION
Max. Power Output: 45 W × 4 channels
AUX IN input
Input sensitivity (load impedance)
AUX IN: 300 mV (10 kΩ)
MAINTENANCE
Cleaning the front panel
When the front panel is soiled, wipe the surface
of the panel with a soft, dry cloth.
Cleaning the connector
The connector on the reverse side of the front
panel needs to be cleaned occasionally. Wipe
the surface of the connector with a cotton swab
slightly moistened with alcohol.
If the display is distorted in any way, cleaning the
connector is recommended.
23
