PREPARATIONS
Connection
Plug in the AC power cord to the wall socket after all other
connections are made.
7 Connect the front speakers.
Connecl the right front speaker to the SPEAKERS R
terminaas and the left to the SPEAKERS L terminals. The
speaker cords with the white stripes go to the © terminals.
2 Connect the supplied antennas.
Connecithe FM antenna to the FM 75 Q terminal and the
MW/LW antenna to the MW/LW LOOP terminals.
MW/LW antenna
3 Connect the AC power cord to the wall socket.
When the AC power cord is connected to the wall socket
for the first time, DEMO appears on the display.
To deactivate the DEMO, press DEMO/ECO.
© Do not short-circuit the & and © speaker cord leads.
¢Do not leave objects generating magnetism or objects
affected by magnetism near the speakers.
Remote control
Detach the battery compartment lid at the rear of the remote
contro! and insert two R6 (size AA) batteries with correct
polarity.
we
E& V
© Replace the batteries with new ones when the operational
distance between the remote control and main unit becomes
shorter.
¢ Remove the batteries if the unit is not going to be used for
an extended period of time.
The remote control may not operate if it is used under intense
sunlight, etc., or if its line of sight is obstructed.
e°4* and "5" of DISC DIRECT PLAY on the remote control
cannot be used on this system.
R6(AA)
4
7 1 ’
Nicati GENERAL
Sp ecifications Power requirements 230 V AC, 50 Hz
a Power consumption 75 W
TUNER Power consumption With ECO mode on: 0.6 W
FM tuning range 87.5 MHz to 108 MHz in standby mode With ECO mode off: 17 W
FM usable sensitivity (IHF) 16.8 dBf Dimensions (W x H x D) 260 x 324 x 339 mm
FM antenna terminal 75 ohms (unbalanced) Weight 5.8 kg
MW tuning range 531 kHz to 1602 kHz (9 kHz step)
530 kHz to 1710 kHz (10 kHz step) PEAKE! 4) 4
MW usable sensitivity 350 uV/m Speaker system 3 way, bass reflex (magnetic
LW tuning range 144 kHz to 290 kHz shielded)
LW
usable
sensitivity
1400
pV/m
Speaker
units
Woofer:
140
mm
cone
MW/LW antenna Loop antenna Tweeter: 60 mm cone
AMPLIFIER erie Eee tweeter: 20 mm ceramic
Power output Rated: 32W+32W(6ohms,T.H.D. — MPecan Onn
1%, 1 kHz/DIN 45500) Dimensions (WxHxD) 220 x 324 x 225 mm
Weight 43kg
Total harmonic distortion
Input
Outputs
CASSETTE DECK
Track format
Frequency response
Recording system
Heads
CD PLAYER
Laser
D/A converter
Signal-to-noise ratio
Harmonic distortion
Reference: 40 W + 40 W (6 ohms,
TH.D. 10 %, 1 KHz/DIN 45324)
DIN MUSIC POWER: 120 W + 120
WwW
0.08 % (20 W, 1 kHz, 6 ohms, DIN
AUDIO)
VIDEO/AUX: 500 mV
SPEAKERS: 6 ohms or more
PHONES: 32 ohms or more
4 tracks, 2 channels stereo
50 Hz - 15 kHz
AC bias
DECK 1: playback x 1
DECK 2: recording/playback x 1,
erase x 1
Semiconductor laser (A = 780 nm)
1 bit dual
85 dB (4 kHz, 0 dB)
0.05 % (1 kHz, 0 dB)
Specifications and external appearance are subject to change
without notice.
