AJAX Hub Plus User Manual

The hub is not connected to the Internet or there
is no connection with the Ajax Cloud server
Lights up red
No power
Lights up for 3 minutes, then blinks every 10
seconds. The color of the indicator depends on
the number of the connected communication
channels
Connecting to the Network
1. Open the hub lid by shifting it down with force.
Be careful and do not damage the tamper protecting the hub from dismantling!
2. Connect power supply and Ethernet cables to the sockets.

AJAX Hub Plus Specifications

General

Ethernet Ports	1
Radio Frequency Bands	868 MHz
Communication Channels	Ethernet
Compatibility	Ajax security system devices
Wireless Range	Up to 2, 000 m in an open space
Encryption	AES-128
LED Indicators	Power
