AJAX Hub Plus User Manual

LED indication
The Ajax logo on the hub front lights up red, white, or green depending on the
status of the power supply and Internet connection.
Event LED indicator
At least two communication channels — Wi-Fi,
Ethernet, or SIM card — are connected
Lights up white
A single communication channel is connected Lights up green
1. LED logo indicating the hub status
2. SmartBracket attachment panel (perforated part is required for actuating
the tamper in case of any attempt to dismantle the hub)
3. Socket for the power supply cable
4. Socket for the Ethernet cable
5. Slot for the micro-SIM
6. Slot for the micro-SIM
7. QR code
8. Tamper button
9. “On” button

AJAX Hub Plus Specifications

General

Ethernet Ports	1
Radio Frequency Bands	868 MHz
Communication Channels	Ethernet
Compatibility	Ajax security system devices
Wireless Range	Up to 2, 000 m in an open space
Encryption	AES-128
LED Indicators	Power
