CONTROLS LOCATION
1 Clutch lever
2 Blinker, lights, horn switch
3 Front brake lever
4 Starter button and On-Off switch
5 Neutral sign
6 Headlight sign
7 Turn light sign
8 Digital speedometer
9 Ignition switch
10 Throttle grip
11 Rear view mirrors
CONTROLS
KEYS
This motorcycle comes with a pair of
keys. Be aware to keep one of the keys
in a safe place, at home for instance, in
order to let you access this key in case
of need.
IGNITION SWITCH
LOCK position – all electrical circuits
are cut off and the engine will not start.
The steering lock is actuated and the
handlebar cannot turn. The key can be
removed. To pass to lock position, the
switch must be in OFF position and the
pushed down and turned to the left. The
handlebar must be turned all the way to
the left.
OFF position - all electrical circuits are
cut off and the engine will not start. The
key can be removed.
ON position – the ignition circuit is on
and the engine can now be started. The
key cannot be removed from the
ignition switch.
! CAUTION !
To activate LOCK position, the
switch must be in OFF position, then
pushed down and turned to the left.
Handlebar should be turned all the
way to the left. If not, the switch will
not pass to LOCK position.
! CAUTION !
Don’t try to ride with the switch on
LOCK position. The steering is
locked and control of the motorcycle
is impossible.
Don’t turn the ignition key to LOCK
position while driving!
.
Note: Start engine as soon as you turn
key to ON position. Otherwise battery
will loose power due to the
consumption of the digital speedometer
and headlight and taillight, if turned on.
LOCK
OFF ON
10
11 11
PR4 User’s manual Page
4
