1. Transparent dust cover
2. Folder selection
3. Audio source
4. Recording button
5. Delete button
6. Earphone jack (3.5mm)
7. Power ON/OFF switch and volume control
8. USB port
9. Card slot for SD card
10. LCD display
11. Backward button
12. Play/Pause button
13. Stop button
14. Forward button
15. Aux in jack (3.5mm)-Line in
16. Tuning knob
17. Radio band switch (AM/ FM/ FM-Stereo)
18. Function switch
19. Adapter for 45 rpm
20. Tone arm set
21. Tone arm lift lever
22. Auto stop ON/ OFF switch
23. Speed switch (33.3, 45, 78rpm)
24. Cartridge with stylus
25. Turntable platter
26. Cassette EJ/ FF button (Eject/ Fast forward)
27. Cassette slot
28. Speakers
29. FM antenna
30. DC IN jack
CAUTION:
Usage of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
This unit should not be adjusted or repaired by anyone except qualified service personnel.
CONNECTION
1. Connect the AC-DC Adapter to your outlet and this unit.
2. Rotate the power/volume control knob in a clockwise direction to turn on this unit.
