Akai MPC Reference Manual

113
6.3 SPECIFICATIONS
Technical overview and specifications of the MPC hardware and software.
MPC Renaissance
HARDWARE
Display
360 x 96 dot graphic LCD w/backlight
Dimensions
(W x D x H)
19.75" x 12.9" x 2.75" (4.9" at max display angle)
502 mm x 328 mm x 70 mm (124 mm at max display angle)
Weight
10.5 lbs. / 4.8 kg
Power Supply
External, 12V DC, 3A, center pin positive
Power Requirement
24 W max
AUDIO & MIDI I/O
Sample Rates
Up to 24-bit, 96 kHz
Monitoring
Zero-latency hardware monitoring via adjustment knob
Record input (L & R)
XLR/ 1/4" combo x 2 (balanced -40 dBu; input impedance 11 kΩ)
RCA stereo (with phono preamp)
Max. Input level
+10 dBu
Digital Input
24-bit RCA-pin x 1 S/PDIF
4 Audio Outputs
1/4" phone x 4 (balanced +11 dBu, output impedance 1 kΩ)
Max. output level
+18 dBu
Phones output
1/4" stereo phone x 1 (200 mW / 100 Ω)
1/8-inch stereo phone x 1 (200 mW / 100 Ω)
Digital output
24-bit RCA-pin x 1 S/PDIF
MIDI inputs
5-pin DIN x 2
MIDI outputs
5-pin DIN x 4
USB
USB 2.0 to computer x 1, plus 2-port, powered USB hub
Footswitches
1/4" x 2
MPC Studio
HARDWARE
Display
360 x 96 dot graphic LCD w/backlight
Dimensions
(W x D x H)
11.2" x 10.1" x 0.89"
284 mm x 257 mm x 22.6 mm
Weight
1.96 lbs.; 0.89 kg
Power Supply
USB bus-powered
MIDI Inputs
5-pin DIN x 1 via 1/8"-TRS-to-MIDI adapter
MIDI Outputs
5-pin DIN x 1 via 1/8"-TRS-to-MIDI adapter
USB
USB 2.0 to computer x 1
