Description of the Receivers 10 (36)
Sesam 800 Operating Manual Document-ID: 941211-000
Version: D1 Author: SH
1
2
3
4
5

Figure3. Sesam 800 RXD
12-24 V DC/AC model
connections
1.Powerconnection
2.Connectiontorelay1
3.Connectiontorelay2
4.Connectiontorelay3
5. Antenna connector
1
2
3
4
5

Figure4. Sesam 800 RXD 230 V AC model
connections
1.Powerconnection,
2.Connectiontorelay1
3.Connectiontorelay2
4.Connectiontorelay3
5. Antenna connector
