HP105/HP405 User manual
Page. 10
Installing/removing the belt clip
The supplied belt allows you to hang the transceiver up to your belt or jacket when you are not using the
radio and you are just in stand-by condition (ready to receive calls).
To fit the belt clip onto the transceiver’s body:
1) Just gently slide the clip into the appropriate
guides located in the transceiver’s back until it
firmly locks.
To remove the belt clip:
2) Press the belt clip spring;
3) Reverse the over stated step 1.
Charging the battery pack
To charge the supplied battery pack you have to setup the standard charger and connect the radio as
follows:
1) Connect the jack coming from the AC adaptor to
the cradle’s socket.
2) Connect the AC plug of the AC adaptor’s power
cable into an earthed AC power outlet.
3) Ensure that the radio is switched off.
4) Insert the radio into the cradle with the keypad
toward you (the three metallic contacts of the
battery pack must touch with the three contacts
inside the cradle).
5) Wait 8-9 hours and remove the radio after that
time.
!
Don’t remove the radio before 8 hours,
otherwise the battery’s duty could be
temporarily reduced.
"
Don’t forget to remove the radio after 9 hours.
"
The battery charger is for indoor use only.
"
For the next charges, best duty and battery life please fully see the chapter “Battery Packs”.
1
2
3
SLIDE DOWN
LIFT UP
PUSH
