10
Lock release
Common
Microphone
Loudspeaker
Electronic call
TERMINALS AT REST WORKING
5 V
9 V
0 V
0 V
0 V
5.6 - 6.6 V
9 V
Audio max 4 Vpp
Audio max 7.0 Vpp
Tone max 7 Vpp
Audio ground
1
2
3
4
5
AUDIO
VIDEO
Video signal common
Power supply ground
Video ground
V1
Video signal
Ground
Power supply voltage
15 V
INACTIVE
5 V
0 V
0 V
0 V
M
0 V
1 Vpp ±0,25 (75 Ω)
12 34 5
V1
V1
25
26
27
28
24
M
M
Code 9630002
MONITOR CONNECTIONS BRACKET
SCM-010
Bracket for the wall mounting of the video door
entry monitor. Analogical 6+N+coaxial system with
confidentiality of audio and video communication. It
includes lift type connection terminals to assure correct
connection. It has several fixing points allowing it to
be fixed to a wall or to a standard 60 x 60mm elec-
trical box.
Operating temperature +5 to + 55ºC
193 mm
166 mm
Description of terminals and voltages:
