EXTERNAL ACCESS VIDEO UNIT ACCESSORY
FIXING TO THE FLUSH-MOUNTED BOX
Fix the video unit accessory to the flush-mounted box
with the 4 screws supplied. Make sure that the place cho-
sen is within reach of the connector which joins the video
unit accessory to the audio unit.
SURFACE WALL-MOUNTED BOX
ENTRANCE PANEL ACCESSORIES
BREAKING THE PERFORATED HOLES
The surface wall-mounted box has several perforated
holes to pass the cables through. Break the ones you
need.
PLACE AND HEIGHT OF PANEL POSITION
Choose a place for the surface wall-mounted box so
that when the entrance panel is fitted, rain, sun rays or
strong light sources do not adversely affect the video
unit. In this way you will avoid certain problems in the
visualisation of images such as the ghosting effect cau-
sed by background light; this will also protect the wor-
king life of the equipment.
Remember to pass the cables through the cable holes
before locating the surface wall-mounted box.
Fix the surface wall-mounted box to the wall with the
screws and wall plugs provided with the product. Place
the box vertically and in such a way that the top part is
at a height of 1.7m from the floor.
