Alcad 201 Series User Manual

58
TAP-OFF
CONNECTIONS
M
M
M
DIV-024
cod. 9730031
Video signal common
M
Video signal input
Outputs to monitors
Through output
M
M
M
Next tap-off
Monitors
V1, M
V1, M
V1, M
V1, M
Video signal input
Monitors
For installing tap-offs in serial, steps 1 and 2
(except for terminal tap-off)
2
1
75 Ohm
DIV-024
cod. 9730031
Internal
conductor
Mesh
COAXIAL
CABLE
Make the terminal connections as shown. For more information consult the installation wiring diagrams at the back
of this manual.
Wiring diagrams:
Description of terminals:

Alcad 201 Series Specifications

General

Brand	Alcad
Model	201 Series
Category	Intercom System
Language	English
