Alcad 201 Series - Configuration of a Video Door Entry Installation

65
CONFIGURATION OF A VIDEO DOOR ENTRY INSTALLATION
22
SECTION TABLE
Up to 100 m
1,1 mm
0,6 mm
0,25 mm
2
AWG
17
1 mm
2
COAXIAL 75 Ω
5
5
2
2
SCM-010
MVB-001
ABR-001
1
2
2
2
COAX
MVN-001
4+N
DIV-024
5
2
5
2
ALA-040
230 V
V
230 V
ALM-040
V
MVB-001
SCM-010 SCM-010
SCM-010
MVB-001
MVB-001
1
DIV-024
MAN-041
MPD-004 X 2
SCM-010
MVB-001
TES-001
2
Steps to be carried out when configuring an installation:
1. Design of the general layout of the installation
2. Estimation of the necessary materials
The following examples show in detail the choice of the necessary materials according to the installation that is to be
made.
Example 1 – Standard video door entry installation for 16 houses or flats.
Special features:
One house or flat with two monitors.
One house or flat with a monitor and a telephone.
1. GENERAL LAYOUT DIAGRAM OF THE INSTALLATION
