Alcatel-Lucent OmniPCX Office RCE Medium

- Energy consumption: 1.5 A (240 V)
- Dimension: H = 345 mm; W = 370 mm; D = 65 mm.
- Weight: 5.1 kg.
The following mixed boards are available:
- MIX 2/4/4
- MIX 2/4/8
- MIX 2/8/4
- MIX 4/4/8
- MIX 4/8/4
- AMIX-1 4/4/4
- AMIX-1 4/4/8
- AMIX-1 4/8/4
- Mini-MIX (PowerCPU daughter board)
Note:
This wall-mounted version is also called XS-N.
The Mini-MIX daughter board, plugged on a PowerCPU booard, requires an OmniPCX Office
RCE Compact, or, in case of migration from Release 7.1 or lower, a Compact Edition 2nd
Generation. The Mini-MIX daughter board cannot be used on an Alcatel-Lucent OmniPCX
Office Compact Edition.
The PowerCPU board shows a Mini-MIX LED activated when the Mini-MIX daughter board is
detected on the PowerCPU board.
