Note:
*: the mix of IBS DECT and IP-DECT solutions is not supported.
This hardware must be installed on the customer's site, by a qualified installer, in
compliance with the instructions provided with the hardware.
Equipment shall be installed at the factory or in the field by submitter's trained personnel
in accordance with the installation instruction provided with the equipment.
2.4 Equipment
2.4.1 Boards and Options
The following table lists the boards available on OmniPCX Office RCE Small, Medium, Large.
Board Function Optional boards Connections
APA2
APA4
APA8
2, 4 or 8 analog trunk line inter-
faces
GSCLI: Ground Start
signaling
CLIDSP: CLIP local
management
Analog trunk line (TL), TL-
PS diversion
ATA2
ATA4
2 or 4 analog trunk line inter-
faces
MET: pulse meter re-
ceivers (phased out)
Analog trunk line (TL), TL-
PS diversion
BRA2
BRA4
BRA8
2, 4 or 8 T0 basic accesses ISDN network
ISDN-EFM T0/S0 forward-
ing box
PowerCPU Processing Unit (As of R8.0),
SD/MMC Memory card (2GB),
256 MB DDR2 SDRAM.
Optional Hard Drive
HSL1, HSL2: intercon-
nection with expansion
modules
AFU-1: (Auxiliary Func-
tion Unit)
ARMADA VoIP32: VoIP
channels
Lanswitch or Ethernet ter-
minal
Please-wait message player
Tuner for background music
Alarm
Doorphone
Loudspeaker
General call ringer
ISDN-EFM T0/S0 forward-
ing box
Pulse metering device
OMC
DDI2
DDI4
2 or 4 analog trunk line inter-
faces with Multiple Subscriber
Numbers (MSN)
Analog trunk line with Mul-
tiple Subscriber Numbers
(MSN)
LanX8
LanX16
LANX16-1
LanX8-2
LANX16-2
8 or 16 port Ethernet 10/100 BT
(of which 1 or 2 10/100/1000 BT
ports on LANX-2 boards)
@ Phones, Hub, Lanswitch,
PC, etc.
Chapter
2
! "# "$
2-6
