Alcatel-Lucent OmniPCX Office RCE Medium User Manual

The DHCP offer provides the following parameters:
- IP address
- Router IP address
- Subnet mask
- Option 66: IP address or name of the Alcatel-Lucent OmniPCX Office Communication
Server:10443, for example 192.168.12.34:10443
- Suboption 67 of option 43: the value of this sub-option corresponds to the DM Url.It must
contain a string value set to /dmcfg/
- Option 58: VLAN ID: this is sent as a suboption of option 43
Optionally, the DHCP offer can include the following parameters, which can also be configured
locally on the terminal or on the Alcatel-Lucent OmniPCX Office Communication Server:
- Option 6: Domain Name Server (DNS primary and secondary)
- Option 15: Domain name
- Option 12: Host name (eg, ICTouch<MAC>)
- Option 42: SNTP server
- Option 120: SIP server (outbound proxy server address or name)
Commissioning the Set in Static Mode
Selecting the Set Initialization Mode (Static)
By default, a set is configured to initialize in dynamic mode.
To modify the initialization mode:
1. Open the set administration menu (see: Accessing the set administration menu )
2. From the set administration menu, scroll up/down to display IP parameters and press OK
3. Scroll up/down to display IP mode: xxxx
The available initialization modes are: Dynamic (default option), Alcatel Dyn or Static
If the desired mode is displayed, you can skip IP mode selection
4. If Dynamic is displayed, press successively OK to change the initialization mode in Static
5. Scroll up/down to display Save and press OK
Configuring the Set IP Parameters
1. Open the set administration menu (see: Accessing the set administration menu )
2. From the set administration menu, scroll up/down to display IP Parameters and press OK.
3. Scroll up/down to display and modify set IP parameters:
• IP @: Set IP address
• Subnet: IP subnetwork mask
• Router: Router IP address
4. After the Router parameter, scroll up/down to display Save and press OK
Configuring the binary and configuration file download parameters
  &'(
        
4-37

Alcatel-Lucent OmniPCX Office RCE Medium Specifications

General

Model	OmniPCX Office RCE Medium
Capacity	Up to 200 users
Maximum number of users	200
VoIP Support	Yes
Protocols Supported	SIP, H.323
Analog Ports	8
Power Supply	100-240 VAC, 50/60 Hz
Storage Temperature	-20°C to 70°C
Humidity	10% to 90% non-condensing
Type	IP PBX
Operating Temperature	0°C to 40°C

Summary

Chapter 1 General Presentation

1.1 Preliminary

Provides an overview of the system, including preliminary information and safety rules.

1.2 Security

Details safety rules, declarations of conformance with directives, and interface classification.

1.3 Protection against Interferences

Outlines measures and notices for protecting against harmful interference, including FCC and VCCI regulations.

Chapter 2 Hardware: Platform and Interfaces

2.1 Overview

Introduces the OmniPCX Office Communication Server and its platform range.

2.2 Platforms

Describes available OmniPCX Office RCE platform models: Compact, Small, Medium, and Large.

2.3 Installation

Provides an overview of the installation process for the system.

2.4 Equipment

Details the available boards and options for the OmniPCX Office RCE platforms.

Chapter 3 System Services

3.1 Software Licence Management

Explains how software licenses define system service levels and manage features.

3.2 Software Keys

Describes the role of software keys (MAIN and CTI) in enabling system functions.

3.3 Detailed description

Provides detailed descriptions of services controlled by the Main and CTI software keys.

3.4 Descriptions

Details system services like standard telephony, mobility, networking, and VoIP.

Chapter 4 Installation and Cabling

4.1 Presentation

Covers the unit's location options: wall mounting, rack mounting, and table placement.

4.2 Connections and Cabling

Details physical connections and cabling for various boards and terminals.

4.3 Power Supply

Explains installation procedures for external power supplies and battery implementation.

4.4 SIP Terminals

Provides commissioning and configuration details for 8002/8012 Desk Phones and SIP phones.

4.5 8 Series Sets

Details commissioning for IP Touch 4008/4018 phones, including static and dynamic initialization.

4.6 9 Series Sets

Covers commissioning for IP Touch 4028/4038/4068 phones and their related modules.

4.7 V24/CTI Interface Module

Describes the hardware, standards, and connections for the V24/CTI Interface Module.

4.8 AP Interface Module

Details the AP Interface Module for connecting analog peripherals, its standards, and configuration.

4.9 S0 Interface Module

Explains the S0 Interface Module for connecting S0 terminals, its standards, and connections.

4.10 Intelligent Base Stations

Provides installation recommendations, safety rules, and coverage details for DECT base stations.

4.11 IP-DECT Base Stations

Details the IP-DECT system, its connection, power, and LED status indicators.

4.12 PIMphony

Introduces PIMphony, a personal productivity tool connecting phone terminals to computers.

4.13 Reflexes Terminals

Covers installation procedures for Premium and Advanced Reflexes terminals, including mounting.

4.14 Extending Your Installation

Explains how to replace terminals, add modules, and manage connections for installation extensions.

4.15 My IC Social Networks

Details the installation, network topologies, and licensing for the My IC Social Networks application.

4.16 ACD applications

Lists supported platforms and installation requirements for ACD applications.

Chapter 5 Stations Default Configuration

5.1 Detailed description

Provides default key functions for IP Touch and Digital Phone sets based on configuration.

5.1.1 Default configuration

Details default F1/F2 and virtual key functions for various phone models and modes.

Chapter 6 Start-Up

6.1 System Startup from a Phone Set

Guides the initial system configuration using a phone set for basic setup.

6.2 System Startup from OMC

Details the PC application OMC for system programming, including minimal configuration requirements.

Chapter 7 Maintenance Services

7.1 Maintenance Level 1

Provides maintenance advice for hardware components, focusing on battery and ventilation.

7.1.1 Maintenance

Covers battery maintenance, ventilation system cleaning, board replacement, and hard disk care.

Chapter 8 Glossary

8.1 A

Defines terms starting with 'A', covering ACD, ACSE, ADN, AFU-1, AMIX-1, AP, APA, API, ARI, ARS, ASN-1, ATA.

8.2 B

Defines terms starting with 'B', including BACKGROUND MUSIC, BACP, BAP.

8.3 C

Defines terms starting with 'C', such as CA, CCP, CHAP, CIFS, CLIP, CLIR/COLR, CNIP, COLP, CONP, CPU, CSTA, CTI, CTL.

8.4 D

Defines terms starting with 'D', including DAP, DASS2, DDI, DECT, DHCP, Direct RTP, DISA, DLL, DLT0, DLT2, DNS.
