4. Push plunger (4-10) into upper sleeve
(4-7). Drop into cylinder from the bottom
side of cylinder.
CAUTION - DO NOT PUSH SLEEVES PAST
THE BLEED PLUG (4-2) HOLE.
5. Push seat (4-13) into lower sleeve (1-16).
Turn over and drop ball (4-19) into sleeve.
Smear Iubriplate on guide (1-20) and
insert into sleeve. Drop into cylinder.
6. Install spacer (4-21) and O-ring (4-25).
7. Push back-up ring (4-26) on gland (4-22).
use plunger (4-28) as a guide and install
gland in cylinder. Remove plunger. (A
brass rod may be used to tap components
into place.)
8. Install sleeve (4-27) loosely using Wrench
100878. Do not tighten sleeve as this will
unseat cap, (4-5).
9. Install hydraulic fluid diaphragm (4-4) and
bleed pIug (4-2).
10.Assemble cylinder assembly to handle
assembly per instructions in Major
Subassemblies Section. Sleeve (4-27) will be
tightened and plunger (1-28), spring (4-29)
and adjusting screw (4-30) installed during
this operation. If handle assembly is not
being installed on cylinder assembly at this
time, plunger, spring and adjusting screw may
be installed loosely for storage purposes.
