Alcoa 200 - Model 200 Installation Kits

200 Series Tooling Alcoa Fastening Systems
38
The Huck Model 200 Installation Tool is available
in kit form which allows the purchase of one part
number that includes the 200 Tool, Carrying
Case, Nose Assemblies, etc. as shown below.
Table 6: 200-52 (Ref. NSN 5130-014-1979)
Part NO. PART NAME PART NO. PART NAME
200 Installation Tool 104271 Inner Anvil -4
78972 Nose Assy 100V-4 83289 Outer Anvil -4
78973 Nose Assy 100V-5 83290 Thrust Bushing -4
78974 Nose Assy 100V-6 100820 Inner Anvil -5
79626 Nose Assy -8 Rivet 83294 Outer Anvil -5
99-1601T-352 Nose Assy -05 GP Tens 83295 Thrust Bushing -5
99-2555CH Nose Assy -06 GP Chis 100799 Inner Anvil -6
99-86 Nose Assy -08 OSR 83296 Outer Anvil -6
G58-1 Grip Gage 1/8 & 5/32 83297 Thrust Bushing -6
G58-2 Grip Gage 3/16 & 1/4 42-233 Service Kit
105805 Nose Assembly Brush 110206 Carrying Case
105806 Nose Assembly Brush
Table 7: 200-53 (Ref. NSN 5130-778-1675)
Part NO. PART NAME PART NO. PART NAME
200 Installation Tool 78974 Nose Assy 100V-6
78972 Nose Assy 100V-4 42-233 Service Kit
78973 Nose Assy 100V-5 110206 Carrying Case
Table 8: 200-54 (Ref. NSN 5130-908-3262)
Part NO. PART NAME PART NO. PART NAME
200 Installation Tool 110206 Carrying Case
42-233 Service Kit
