Alcolizer WM4 - 11 Networks; Configuration; Network Setup

REF: WM4 User Manual V7.docx Page 29 © Alcolizer Technology
11 Networks
11.1 Configuration
The configuration panel provide general information about the network connection and
device.
11.1.1 Network Setup
The network IPv4 Configuration can be set to obtain an IP address automatically or use a
static IP address.
Establish an internet connection as follows:
a. Connect the WM4 to an internet receptacle via the Ethernet cable.
b. Connect a keyboard/mouse and access the User Menu in accordance with the
procedures at paragraph 7.1.
c. From the User Menu, access the network configuration screen by scrolling
down to Network and pressing space bar. The Network Configuration page
will appear
d. Complete the Configuration page with the required details to establish the
network connection if a Static IP address will be used or select “Obtain an IP
address automatically”.
