Alde Compact 3020 HE Installation Instructions

21
GB
11. ACTIVATION OF INSTALLED FUNCTIONS
The rst time you use the heating system, check that the right accessories/functions are activated.
This also applies when you supplement the heating system with accessories/functions.
Activate accessories/functions by pressing on Installed Accessories, (see gure 1) and checking the box for the func-
tion/accessory in question to activate (see gure 2 to 5).
Inst Acc
Third party Panel
Load Monitor
1/4
Settings
4/4
Figure 1
Figure 2
Inst Acc
Main Remot 12V
Main Manual 12V
2/4
Inst Acc
Duo Control
Booster
EisEx
3/4
Inst Acc
Alde Flow
Underfloor Heating Pump
Engine Pre-Heat Pump
4/4
Figure 3
Figure 4 Figure 5
The relevant box must be checked if you have:
Connected an external panel or Alde Smart
Control (part no. 3020 057).
Connected a gas bottle changer
(DuoComfort or DuoControl).
Connected a load monitor. Connected a defroster (EisEx).
Connected a 12 V pump that can be variably
adjusted manually.
Connected a 12 V pump to the underoor
heating.
Connected a PWM controlled 12 V pump that
has variable speed control and is set from the
panel.
Connected an additional hot water tank to
increase the hot water capacity and also obtain
continuous hot water (part no. 3020 160).
Connected a booster. Connected a 12 V pump for heating the vehi-
cle’s engine through the Alde heating system.
