FITTED EQUIPMENT
104
ALDE HEATING OPERATING INSTRUCTIONS
The instructions covering fitted equipment
to your caravan were correct at the time
of going to print. Owners handbooks are
updated annually and we take great care
to try and ensure their accuracy. However,
the Swift Group Limited cannot accept
responsibility for any changes that may
be made in specification or operating
instructions to the equipment described in
this section after the time of going to press.
Every care is taken to ensure that the
information provided in this handbook is
correct and easy to understand.
Separate manufacturers’ leaflets on many
of the components are also included in the
Owner’s Pack provided with this caravan
and we recommend that you compare
the instructions in the handbook with
the component manufacturers literature,
to ensure the information provided is as
accurate as possible.
If you are in any doubt as to how to operate
the equipment in your caravan, please
contact the component manufacturer’s
service department on the telephone
number shown on their component leaflet.
If you remain in any doubt, please contact
your supplying dealer.
Notice: In the interest of safety, replacement
parts for an appliance shall conform to the
appliance manufacturer’s specifications and
should be fitted by them or their authorised
agents.
Alde Compact 3020
! WARNING: Alde can accept no liability
whatsoever for damage or injury resulting
from failure to observe these instructions.
Specific Use
These instructions are approved for the Alde
3020 Compact HE boiler fitted in caravans,
motorhomes or buildings in accordance with
CE 0402 no. SC0653-13, and have the E5
mark for installation in vehicles in accordance
with ECE R122, no. 00 001 and R10, no. 04
166, for use in central heating and hot water
systems.
The boiler is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and/or knowledge, unless they
have been given instruction or are supervised.
The term “specified use” also covers
observance of the operating and installation
instructions.
The Alde 3020 Compact HE boiler must be
installed or repaired by a competent person in
accordance with current local regulations.
In the unlikely event that your boiler develops a
fault, switch off the boiler and contact Alde, or
your dealer or installer.
Operating and installation instructions for the
Alde control panel are supplied separately.
The owner is always responsible for
maintenance and arranging inspection.
Boiler Design
The boiler’s internal heat exchanger consists
of three concentric cylinders; the combustion
chamber, the central heating cylinder and the
hot water cylinder.
The combustion chamber is made from
aluminium, and is divided into two halves by
a baffle plate, with the burner head located
in the top half, and the flue gases venting
through the bottom half.
The combustion assembly is fixed to the end
of the internal heat exchanger. It consists of
